Standard Features

Tank and Trailer

Low-profile, patented “stealth” tank design improves rear vision and improves stability
Excellent axle adjustability
Choose from 4 tank capacities: from 1050, 1350, 1800, or 2400 gallons
Single-reach tongue enables a sharper turning radius with less crop damage
Short-coupled trailer minimizes crop damage on hills and during turns, resulting in greater yield
Long-lasting hydraulic pump features a flow limiter for overspeed protection
2-speed heavy-duty jack stand with safe and easy hooking and unhooking
Dual-wheel capable with three axle width options

High crop clearance

Baked-on powder coat paint resists effects of harsh chemicals, increasing equipment life and resale

Toolbar

• Flexible Row Spacing Options – 10” to 40”
• 7″x7″ single tube toolbar used on 20″-40″ coulter spacing
• 5″x7″ double tube toolbar used in 10″ and 15″ coulter spacing (only available with a 1800 or 2400 gallon tank)
• External hydraulic fold cylinder enables operator to fold in the toolbar at the maximum length and still use it at the lesser length
• Trademarked wing kick feature engages when toolbar is lifted up, tilting up the outer wings, resulting in less crop damage
• Hydraulic down pressure on the wings gives coulters better ground penetration and more consistent application, ultimately resulting in higher yields
• Flexing toolbar promotes better ground penetration, even depth control and fertilizer placement in uneven terrain
• Two-gauge wheels help achieve consistent application across toolbar

Fast Cast AP Coulters

• Patented AP coulter design places nitrogen at a consistent depth and flexible mounting
• Coulter is cast for long term-durability, ability to offset shank in eight different positions, and increased stability in varying soil conditions
• Coulter casting increases stability and minimizes deflection in the field, resulting in more consistent nitrogen placement
• Hex shank design allows toolbars to match up with nearly any row spacing and provides ability to offset 7.5” to the left or right quickly without additional brackets
• Ability to set degree of coulter swivel

Technology

• Every Fast liquid fertilizer applicator can be equipped with an ISO rate controller (Raven RCM or John Deere Greenstar) to work seamlessly with your in-cab tractor display to offer mapping, auto section control, and variable rate capability.
• Capstan Tattler System - Electronic Flow/Blockage Detection, Variable Rate Nozzles, and Rate Control. Fully integrated ISO system that provides electronic flow/blockage detection and rate control integrated into one screen/page on your tractor's ISO display. System is unique as it has a very wide flow range with the ability to flow 0-8 GPM per row and provides much more consistent row-to-row flow distribution compared to other variable rate nozzles. Saves time by eliminating the need to change tips or orifices when changing rates and allows for variable rate/prescriptions to be used in the field. Available as a factory installed option on all Fast Applicators.

Specifications
